ProfiPlane LED L RGB Spot /DMX/02

The ProfiPlane LED L RGB Spot / DMX / 02 is the powerful, robust RGB-LED light with flange and hole D=22mm and a beam angle of 16°, 837 lumens.

  • Characteristic

    • Strobe effect
    • DMX/RDM-capable in combination with the Underwater LED Driver Compact (70468)
    • Flat surface due to stepped glass
    • Wet and dry installation - waterproof IP68 / 4m
    • Temperature controlled high class brand LED
    • 1 m cable length with patented, watertight plug connections
    • For fresh-, pool- and sea water
    • External electronic in a separate control box / junction box - waterproof connector, easy to connect.
    • Individual measurement of the basic colours of the LED-RGBW lights and the use of the Underwater LED Driver /DMX/02 guarantees equal brightness of all lights in the system and a homogeneous colour combination
    • Galvanic isolation between the DMX and 24V DC power
    • Lifetime: 100,000 h*
    * In case of underwater application, an intelligent heat management and quality LED enables a lifetime of up to 100,000 hrs. This claim does not entitle to a guarantee.

Technical Data

DMX Channel 1red
DMX Channel 2green
DMX Channel 3blue
DMX Channel 4strobe
DMX Channel 5dimmable
Luminous flux with all onlm837
Luminous flux redlm240
Luminous flux greenlm460
Luminous flux bluelm137
Beam angle16 Degrees (± 2)
Stroboscope effect0-25 Hz
Weighted energy consumptionkWh/1000h24
Rated voltage24 V / DC
Power consumptionW21
Rated currentA0.95
Dim frequencyHz2800
Power connection typeHybrid plug
Power cable lengthm1.00
Protection classIP68; 4 m
Dimensions (Ø x H)mm180 x 30
MaterialStainless steel 1.4404 (AISI 316L)
Net weightkg1.60
